Product Code :
Easy
- Features
- Technical Specifications
Features
| Remote Control |
| Refrigerant type R410A |
| Hydrophilic aluminium |
Technical Specifications
| Model | EASY-09H10 | EASY-12H10 | EASY-18H10 | EASY-24H10 | EASY-30H10 | ||||||
| Capacity (Btu/h ) | Cooling | 9,000 | 12,000 | 19,000 | 24,000 | 29,800 | |||||
| Capacity (Btu/h) | Heating | 9,500 | 12,500 | 20,000 | 23,500 | 31,000 | |||||
| Rated current | Cooling | 3.4 | 4.5 | 7.1 | 8.9 | 12.6 | |||||
| Rated current | Heating | 3.4 | 4.6 | 7.5 | 8.6 | 11.5 | |||||
| EER | W/W | 3.43 | 3.43 | 3.42 | 3.42 | 3.01 | |||||
| COP | W/W | 3.62 | 3.61 | 3.47 | 3.62 | 3.43 | |||||
| input consumption ( Cooling ) | W | 770 | 1025 | 1623 | 2056 | 2900 | |||||
| Indoor unit Dimension | W*D*H | 717x193x300 | 805x193x302 | 964x222x325 | 1106x232x342 | 1106x232x342 | |||||
| Outdoor unit Dimension | W*D*H | 770x300x555 | 842x322x555 | 914x376x707 | 914x376x707 | 845x363x702 | |||||
| Outdoor noise level | dB(A) | 55 | 57 | 60 | 61 | 59 | |||||
| Indoor noise level | Hi | 38 | 40 | 44 | 48 | 47 | |||||
| Indoor noise level | Mi | 33 | 34 | 39 | 45 | 41 | |||||
| Indoor noise level | Lo | 28 | 28 | 34 | 40 | 34.5 | |||||
| Indoor air flow | Hi | 420 | 500 | 830 | 1060 | 1080 | |||||
| Indoor air flow | Mi | 350 | 400 | 700 | 900 | 910 | |||||
| Indoor air flow | Lo | 290 | 320 | 560 | 730 | 735 | |||||
| Room temperature (Indoor(cooling/ heating)) | ℃ | 17～32/0～30 | 17～32/0～30 | 17～32/0～30 | 17～32/0～30 | 17～32/0～30 | |||||
| Room temperature (Outdoor(cooling/heating)) | ℃ | 18～43/-7～24 | 18～43/-7～24 | 18～43/-7～24 | 18～43/-7～24 | 18～43/-7～24 | |||||
| Liquid side/ Gas side | mm(inch) | 1/4-3/8 | 6-10 | 1/4-1/2 | 6-12 | 1/4-1/2 | 10-16 | 3/8-5/8 | 10-16 | 3/8-5/8 | 10-16 |
| Max. refrigerant pipe length | m | 20 | 20 | 25 | 25 | 25 | |||||
| Max. difference in level | m | 8 | 8 | 10 | 10 | 10 | |||||
| Compressor | type | ROTARY | ROTARY | ROTARY | ROTARY | ROTARY | |||||
| Compressor | brand | GMCC | GMCC | GMCC | GMCC | GMCC | |||||
